Smart Socket/Switch Module
Smart Socket/Switch Module
| Specification | Details |
|---|---|
| Operating Voltage | DC 5V-12V |
| Operating Current | Above 250mA |
| Communication Module | ESP-01 or ESP-01S WiFi module |
| Transmission Distance | Peak transmission distance up to 400 meters (open environment, with WiFi module-equipped phone) |
| Load | 10A/250Vac, 10A/30Vdc, relay pulls 100,000 times |
| Control | ESP-01/01S GP100 controls relay (active low) |
| Module Dimensions | 37*25mm |
Features
This relay is designed for DIY projects in smart homes and the Internet of Things. With this smart relay, you can easily control any device via a smart switch, regardless of where your phone is located. It supports applications and LUA source code.
